7463-NWO-FG
SAE J1926/ISO 1179/SAE J514 Male Adjustable x Female Port x Tube Cross | Male Adjustable O-Ring Boss x Female BSPP x Male JIC x Male JIC
Connection Details
| PART NUMBER ↑ | SIDE 2 THREAD TYPE | SIDE 3 TUBE OD | SIDE 3 THREAD TYPE | SIDE 4 TUBE OD | SEAL MATERIAL | PRIMARY MATERIAL | PLATING |
|---|---|---|---|---|---|---|---|
| 7463-08-06-08-08-NWO-FG | 3/4-16 UNF | 1/2" | G - 3/8-19 | 1/2" | Buna-N (Nitrile) | Steel | Trivalent Zinc |
| 7463-10-06-10-10-NWO-FG | 7/8-14 UNF | 5/8" | G - 3/8-19 | 5/8" | Buna-N (Nitrile) | Steel | Trivalent Zinc |
Description
SAE J1926/ISO 1179/SAE J514 Male Adjustable x Female Port x Tube Cross | Male Adjustable O-Ring Boss x Female BSPP x Male JIC x Male JIC
Additional information
| Shape | Cross |
| Side 1 Connection Type | Male Adjustable ORB |
| Side 2 Connection Type | MetaobjectDrop |
| Side 3 Connection Type | MetaobjectDrop |
| Side 4 Connection Type | MetaobjectDrop |
